Grote 522 - Chart 14: Pendulum Wont Move

Slicer/Applicator
SS-10.DOC:1/26/2007 11:08 AM Grote Company 47
Chart 14: Pendulum Won’t Move
Is Blade Running
Pendulum Won’t Move
(Hydraulic Slicers)
Check Pump Rotation
and Pressure
(Hydraulic Slicers) Check pressure gauge for proper setting
and pressure output.
Check Product Box
Pull Pin
Check for proper blade rotation.
Check for mechanical jam.
Check Clutch And
Clutch Coil
Voltage supply to clutch coil at proper supply. Check supply
from switch, TDR or PC.
Shuttle Or Shuttle
Linkage Jammed.
Check for mechanical jam on shuttle and pusher linkage, if
used.
