Grote 522 - Troubleshooting; Product Quality Issues

Slicer/Applicator
SS-10.DOC:1/26/2007 11:08 AM Grote Company 39
Chart 3: Product Not Stacking Or Laying Down Properly
Proper Amount of
Water
Improper Distance
From Slicer To
Shuttle, Conveyor or
Target
Product Not Stacking Properly or Laying Down Properly
Blade Dull Or
Inside Out
Improper Stroke
Length
Replace blade. Check blade for proper bevel installation.
Stroke 1/8 before the blade in the home position.
Stroke 1/8 after the leading edge of the blade guide.
Over stroke with fingers. Check manual for proper
setting.
Improper Loading
Of Product
Product Transfer
Fingers Bent,
Missing Or Jammed
(Non Water-
Injected Blade Guide Machines) Refill water
reservoir
. Check water applicator pad for product
residue. Adjust control valve or timer.
Locate shuttle as close as possible to conveyor or
target. Distance should be less than half the product
size.
Stop machine. Check product and tube sizes for
proper fit.
Check transfer fingers for excess product build-
up,
clean, straighten, or replace.
Improper Slice
Position On Shuttle
Improper Product
Holder Clearance
Product leading edge must land within first three links
of the shuttle belt.
No less then 1/32 no more then 1/16 from trailing
edge of product holder to the blade (See Page 19).
Shuttle Roller
Clutches Not
Operating Properly
Stop. Remove shuttle from frame, rotate clutches
manually. If not operating properly, replace.
