Grote 522 - Page 57

SPARE PARTS LIST
SERIAL # 1065029
PENDULUM SLICER, MOD# 522
PART NUMBER DESCRIPTION
1000046 BEARING, BALL, SGL ROW, 20 MM ID
1000047 BEARING, BALL, DBL ROW, 20 MM ID
1000083 VALVE, HYD FLOW CONTROL, ADJ
1000088 PUMP, HYD, 6 GPM, PISTON
1015258 SEAL KIT, COMPLETE, PVB5/6 PUMPS
1000144 ROLLER CHAIN, #40, RUSTLESS
1000154 FILTER, RETURN LINE, COMPLETE
1000090 FILTER, RETURN LINE, CARTRIDGE ONLY
1000190 ROD END, MALE, .375" ID BEARING
1000489 GAUGE, PRES, 0-2000 PSI, REAR MOUNT
1000503 FUSE, 3 A, FNM, 13/32 X 1-1/2
1000556 PLUNGER, SPRING SS, 5/8-11 X 1 1/16
1000586 ROLLER CHAIN, #40 CONNECTING LINK
1000625 VALVE, HYD SHUT OFF, PLUG, BRASS
1000661 BUSHING, SPLIT TAPER, H, 5/8" BORE
1000778 SPRING, COMP, SS
1000867 VALVE, WATER,1/4 NPT MALE & 3/8TUBE
1000891 BEARING, NEEDLE
1001007 IDLE SIDE BRG SIDE SLIDE PADS
1001027 IDLE SIDE BRG TOP&BOTTOM SLIDE PADS
1001567 WASHER, DELRIN, 1.50, 1.01, .125
1001610 BUSHING, SPLIT TAPER, 5/8" PLATED
1001928 SPROCKET, SS, #40, 18T, 1" BORE
1001989 WASHER, DELRIN, 1.25, .626, .150
1003877 BLADE PULLEY, 12.375 CROWN DIA.
1006473 SPRING, COMP, DIE (RED) ##
1127940 SPRING, COMP, DIE (RED) MHP, VINYL
1006860 BEARING, OUTER RING & ROLLER ASSY
1006861 BEARING, INNER RING,1.38" ID
1006881 BEARING, OUTER RING & ROLLER ASSY
1006882 BEARING, INNER RING, .63" ID
1007058 BRG UNIT, ASSEMBLY,(1-3/16)
1007401 PULL PIN, CLUSTER, 13.26 LG
1007613 DRIVE GEAR, CONV
1007623 BUSHING, SLIDE, SHUTTLE DELRIN
1008113 TERMINAL BLOCK
1009151 BLADE GUIDE, 22' CB *OBS
1028659 SCRAPER, BLADE GUIDE SLOT
1028660 WIDTH GAUGE, BLADE GUIDE SLOT
1028661 DEPTH GAUGE, BLADE GUIDE SLOT
1009453 BEARING, INNER RING, .375" ID
1009495 ROLLER, PUSHER BAR
1009594 BLADE SCRAPER, DELRIN, 3.50 LG
1009927 SPRING, COMP, SS
1011336 BLADE WIPER, TOP
1012236 WASHER, DELRIN, 1.25, .890, .250
1013492 BUSHING, DRIVE SHAFT
1024024 FUSE, 4 A, FNM, 13/32 X 1 1/2
1025156 ROLLER CLUTCH, BRG, 5/8 ID, 7/8 OD
1012989 INNER RACE
1025381 CONV BELT, WIRE, 24" FLAT FLEX
1028170 MOTOR, HYD, PLATED, 4.5 CU IN
5/2/2011 Page 1
