Chapter 3: Installation
NOTE: When installing the last flight section (90) to the short flight section (89), after inserting the shaft,
rotate it two revolutions to move the auger blade closer to the last blade of the previous flight
section (89) as shown.
Figure 3-22 Attaching the last flight section
85 Flight section 90
Last flight section
89
Short flight section
