GPT-10000 Series User Manual
18
WARNING
USE EXTREME CAUTION.
Do not touch the HIGH VOLTAGE terminal
during testing.
RETURN
terminal
The RETURN terminal is used
for ACW, DCW, IR and CONT
tests.
OUTPUT and
RETURN
terminals
All models
The OUTPUT terminal (red)
and RETURN terminal (black)
are used for CONT
(Continuity) test.
SENSE H/L and
SOURCE H/L
terminals
GPT-12004,
GPT-15004 only
The SENSE H, SENSE L,
SOURCE H and SOURCE L,
terminals are used for GB
(Ground Bond) test.
