APPENDIX
267
Tester Errors
The following test error messages highlighted in red may appear on the
GPT-10000 display when completing a running test.
Test Error
Description
HI FAIL
Test result is beyond the HI SET value
LOW FAIL
Test result is below the LOW SET value
V OVER
Measured voltage is beyond the set value by 1.1 times
V LOW
Measured voltage is below the set value by 0.9 time
SHORT
Voltage short-circuit detected
GBI OVER
Measured current is beyond the set value by 1.1 times
GBI LOW
Measured current is below the set value by 0.9 time
GBV OVER
Measured GB voltage is beyond 7.2V
CONT V ERR
Measured CONT voltage is beyond 8.0V
ARC ERR
ARC abnormality detected
GFCI ERR
Ground current abnormality detected
SHORT
(CONTACT CHK)
CONTACT CHK greater than HI Limit detected
OPEN
(CONTACT CHK)
CONTACT CHK lower than LOW Limit detected
The following setup error messages highlighted in red may appear on
the GPT-10000 display when abnormality occurs in the settings of
MANU steps.
Setup Error
Description
TEST MODE ERROR
Setting error in ACW/DCW
VOLTAGE SET ERROR
Setting error in voltage
CURRENT SET ERROR
Setting error in current
MANU STEP ERROR
Setting error in MANU STEP value
MANU NAME ERROR
Setting error in MANU NAME
HI SET ERROR
Setting error in HI SET value
HISET <= LOWSET
Set value of HI SET is less than or equal to
LOW SET value
