GW Instek GPT-12004 - Creating a MANU Test File Name

OPERATION
43
Creating a MANU Test File Name
Background
Each manual test can have a user-defined name
(default: MANU_NAME) up to 10 characters
long. See the available list of characters below.
Character List
0 1 2 3 4 5 6 7 8 9
W X Y ZM VO P RQ T USNLA B C D E F G H I J K
w x y zm vo p rq t usnla b c d e f g h i j k
_
Steps
1. Press the UP / DOWN arrow soft-
keys to bring the cursor to the
MANU_NAME (default name) field.
The characters table will appear in
the right hand accordingly.
MANU NAME cursor Characters Table
2. Use the scroll wheel to scroll
through the available characters.
3. Press the LEFT / RIGHT arrow soft-
keys to move the cursor to the next
character.
4. The MANU test file name is set when the
cursor is moved to another setting.
