GPT-10000 Series User Manual
256
Sweep Commands
SWEEP:DATA:STATus ......................................................................... 256
SWEEP:DATA:SHOW ........................................................................... 256
SWEEP:GRAPh:SHOW ......................................................................... 257
SWEEP:DATA:STATus
Query
Description
Returns the basic status of get data.
Query Syntax
SWEEP:DATA:STA?
Return parameter
<String>
The returned string will be in the format
below:
STEP, TEST MODE, V SET, HI SET,
TOTAL DATA
Example
SWEEP:DATA:STA?
> STEP, MODE, V SET , HI SET , TOTAL DATA
000 , DCW , 0.450kV, 1.700mA, 00076
SWEEP:DATA:SHOW
Query
Description
Returns the full measured readings of get data.
Query Syntax
SWEEP:DATA:SHOW<NR1>
Return parameter
<NR1>
0~10000
0 stands for the full steps.
1~10000 indicates the designated step.
Example
SWEEP:DATA:SHOW 0
> TIMER , READ V, READ I
0000.1s , 0.003kV, 007uA
0000.2s , 0.008kV, 026uA
0000.3s , 0.019kV, 064uA
0000.4s , 0.028kV, 095uA
0000.5s , 0.037kV, 126uA
0000.6s , 0.045kV, 153uA
