GPT-10000 Series User Manual
92
Running a MANU Test
Background
A test can be run when the tester is in READY
status.
Note
The tester cannot start to run a test under the
following conditions:
 A protection setting has been tripped; when a
protection setting has been tripped the
corresponding error message is displayed on
the screen. See page 261 for a comprehensive
list of the all the setting errors.
 The INTERLOCK function is ON and the
Interlock key is not inserted in the signal I/O
port (page 144).
 The STOP signal has been received remotely.
 If Double Action is ON, ensure the START
button is pressed immediately after the STOP
button (<0.5s).
Note
When a test is running the voltage output
cannot be changed, unless the test is under the
special manual mode. See page 102 for details.
Steps
1. Ensure the tester is in READY
status for the test to come.
