GW Instek GPT-12004 User Manual

GPT-10000 Series User Manual
268
HISET >= ARC
Set value of HI SET is greater than or equal
to ARC SET value
LOW SET ERROR
Setting error in LOW SET
TEST TIME ERROR
Setting error in TEST TIME
RAMP TIME ERROR
Setting error in RAMP TIME
ARC FUNC ERROR
Setting error in ARC FUNC
ARC SET ERROR
Setting error in ARC SET
ARC SPEED ERROR
Setting error in ARC SPEED
FREQ SET ERROR
Setting error in FREQ of ACW/GB
WAIT >= TEST+RAMP
Setting error in WAIT TIME
GB CONTACT ERROR
Setting error in GB CONTACT
RAMP DOWN ERROR
Setting error in RAMP DOWN
GROUND ERROR
Setting error in GROUND MODE
MAX HOLD ERROR
Setting error in MAX HOLD
PASS HOLD ERROR
Setting error in PASS HOLD
REF SET ERROR
Setting error in REF VALUE
GBV OVER
Setting Error in ISET x (HI SET + REF) > 7.2V
of GB Mode
INIT VSET ERROR
Setting error in INIT VOLTAGE
IR MODE ERROR
Setting error in IR MODE
DCW OVER 50W
(GPT-12XXX)
Setting error in V * I > 50W of DCW Mode
DCW OVER 100W
(GPT-15XXX)
Setting error in V * I > 100W of DCW Mode
DCW OVER 120W
(GPT-15012)
Setting error in V * I > 120W of DCW Mode
GB OVER 200W
Setting error in V * I > 200W of GB Mode
ZERO SET ERROR
Setting Error in ZERO CHECK
CONT. TEST V OVER
Setting Error in ISET(100mA) x (HI SET +
REF) > 8V of CONT Mode
TIME OVER 240s
(GPT-12XXX)
TIME OVER 240s is displayed when, under
ACW test mode, HI SET is greater than
30mA and the RAMP TIME plus the TEST
TIME setting is > 240 seconds.
