APPENDIX
269
TIME OVER 240s
(GPT-15XXX)
TIME OVER 240s is displayed when, under
ACW test mode, HI SET is greater than
80mA and the RAMP TIME plus the TEST
TIME setting is > 240 seconds.
TEST TIME<0.5s
TEST TIME<0.5s is displayed when test time,
under IR test mode with Ground mode ON,
is below 0.5 second.
CONTACT ERROR
Setting error in CONTACT of ACW, DCW or IR.
LEARNING < 30uA
The learned reference value of CONTACT
CHK is less than 30uA and thus CONTACT
CHK function will be invalid.
FILTER SET ERROR
Setting error in IR Mode Filter
