1
At least 0.3 seconds is needed to reach a set
voltage of 50V/10mA.
2
At least 0.3 seconds is needed to reach a set
voltage of 50V/2mA.
3
Test current for CONT is fixed at 100mA
When setting the current, be aware that a maximum
of 200VA can be set for ACW and 50W for DCW,
respectively in terms of GPT-12XXX series.
As for GPT-15XXX series, a maximum of 500VA can
be set for ACW and 100W for DCW, respectively.
And for the specific GPT-15012, a maximum of
120W can be set for DCW.
The ground bond voltage (GBV) is calculated as
the HI SET limit x Test Current.
