GW Instek PSU 100-15 User Manual

PSU Series User Manual
100
External Output Control
Function
F-98
0 = OFF, 1 = ON
Trigger Input and Output Configuration Settings
Trigger Input Pulse
Width
F100
0~60ms. 0 = trigger controlled by
trigger level.
Trigger Input Action
F102
0 = None
1 = Output ON/OFF (refer to F103)
2 = Setting (refer to F104 & F105)
3 = Memory (refer to F106)
Output State When
Receiving Trigger
F103
0 = OFF
1 = ON
Apply Voltage Setting on
Trigger
F104
0 ~ rated voltage (only applicable
when F102 =2)
Apply Current Setting on
Trigger
F105
0 ~ rated current (only applicable
when F102 =2)
Recall memory number
F106
1 ~ 3 (M1 ~ M3)
Trigger Output Pulse
Width
F120
0 ~ 60ms. 0 = trigger output is set to
the active level, not pulse width.
Trigger Output Level
F121
0 = LOW, 1 = HIGH (If F120 = 0)
Trigger Source
F122
0 = None
1 = Switching the output on or off
2 = Changing a setting
3 = Recalling a memory
Special Function Settings*
Calibration
F-00
0000 ~ 9999
*Note
Power on configuration settings only can be set during
power up. Under normal operation they only can be
viewed.

GW Instek PSU 100-15 Specifications

General

Brand	GW Instek
Model	PSU 100-15
Category	Power Supply
Language	English
