PSU Series User Manual
40
the sense leads may be necessary in high noise
environments. Where shielding is used, connect
the shield to the chassis via the rear panel ground
screw. Even if noise is not a concern, the load and
remote sense wires should be twisted-pairs to
reduce coupling, which might impact the stability
of the power supply. The sense leads should be
separated from the power leads.
Output Terminals
Background
Before connecting the output terminals to the load,
first consider whether voltage sense will be used,
the gauge of the cable wiring and the withstand
voltage of the cables and load.
The output terminals are of two types:
- Two solid bars equipped with M8 sized bolt
and nuts for low voltage models (PSU 6-200,
8-180, 12.5-120, 15-100, 20-76, 30-50, 40-38,
50-30, 60-25)
- Clamp block terminals for medium and high
voltage models (PSU 80-19, 100-15, 150-10,
300-5, 400-3.8, 600-2.6).
WARNING
Dangerous voltages. Ensure that the power to the
instrument is disabled before handling the power
supply output terminals. Failing to do so may lead to
electric shock.
Steps
1. Turn the power switch off.
2. Remove the output terminal cover.
Page 42
