CV and CC Slew Rate Priority are disabled for V-I mode
(F-03) when using external voltage control. See the
normal function settings on page 101.
Ensure the polarity is correct when connecting the
external voltage.
Ensure no more than 21mA are input into the external
current input.
The isolated analog connector can also be used to
monitor the current (IMON) or voltage (VMON).
For the isolated voltage option, an output of 0~5V
or 0~10V represents the voltage or current output
of 0~ rated current/voltage output.
IMON = (current output/full scale) × (5 or 10)
VMON = (voltage output/full scale) × (5 or 10)
For the isolated current option, an output of
4~20mA represents the voltage or current output
of 0~ rated current/voltage output.
IMON = ((current output/full scale) × 16mA) +
4mA
VMON = ((voltage output/full scale) × 16mA) +
4mA
