APPENDIX
201
Ripple and noise
*12
r.m.s.
mA
125
95
85
75
57
Temperature
coefficient
ppm/
°C
100 ppm/°C of rated output current, after a 30
minute warm-up.
Model
PSU
100-15
150-10
300-5
400-3.8
600-2.6
Line regulation
*3
mA
3.5
3
2.5
2.38
2.26
Load regulation
*11
mA
8
7
6
5.76
5.52
Ripple and noise
*12
r.m.s.
mA
45
35
25
17
12
Temperature
coefficient
ppm/
°C
100 ppm/°C of rated output current, after a 30
minute warm-up.
Protection Function
Model
PSU
6-200
8-180
12.5-120
15-100
20-76
Over voltage
protection
(OVP)
Setting
range
V
0.6 - 6.6
0.8-8.8
1.25 - 13.75
1.5 - 16.5
2 - 22
Setting
accuracy
mV
60
80
125
150
200
Over current
protection
(OCP)
Setting
range
A
5 - 220
5-198
5 - 132
5 - 110
5 - 83.6
Setting
accuracy
mA
4000
3600
2400
2000
1520
Under
voltage limit
(UVL)
Setting
range
0 - 6.3
0 - 8.4
0 - 13.12
0 - 15.75
0 - 21
Model
PSU
30-50
40-38
50-30
60-25
80-19
Over voltage
protection
(OVP)
Setting
range
V
3 - 33
4 - 44
5 - 55
5 - 66
5 - 88
Setting
accuracy
mV
300
400
500
600
800
Over current
protection
(OCP)
Setting
range
A
5 - 55
3.8 - 41.8
3 - 33
2.5 - 27.5
1.9 - 20.9
Setting
accuracy
mA
1000
760
600
500
380
Under voltage
limit (UVL)
Setting
range
0 - 31.5
0 - 42
0 - 52.5
0 - 63
0 - 84
Model
PSU
100-15
150-10
300-5
400-3.8
600-2.6
Over voltage
protection
(OVP)
Setting
range
V
5 - 110
5 - 165
5 - 330
5 - 440
5 - 660
Setting
accuracy
mV
1000
1500
3000
4000
6000
Over current
protection
(OCP)
Setting
range
A
1.5 - 16.5
1 - 11
0.5 - 5.5
0.38 - 4.18
0.26 - 2.86
Setting
accuracy
mA
300
200
100
76
52
Under voltage
limit (UVL)
Setting
range
0 - 105
0 - 157.5
0 - 315
0 - 420
0 - 630
