OPERATION
89
2. Turn on the power. MS ON (Mass Storage) will
be displayed on the screen after a few seconds
if the USB drive is recognized. Conversely, MS
OFF will be displayed if removed.
VOLTAGE CURRENT
VSR LAN RMT ERR DLY ALM ISR M 1 M 2 M 3 RUN
C V C C
V A
If the USB drive is not recognized, check to see that
the function settings for F-20 = 1 (page 104). If not,
reinsert the USB flash drive.
3. Configure T-02 (Test Copy) to 1~10
(save memory slot)
4. OK will be displayed when completed.
5. The script will now be available in the memory
slot the script was saved to.
Error messages: If you load a file that is not present on
the USB drive “Err 002” will be displayed on the
display.
VOLTAGE CURRENT
VSR LAN RMT ERR DLY ALM ISR M 1 M 2 M 3 RUN
C V C C
V A
Run Test Script
A test script can be run from one of ten memory
slots.
1. Before a test script can be run, it
must first be loaded into one of the
10 memory save slots.
To Next Page
