OPERATION
91
2. Turn on the power. MS (Mass Storage) will be
displayed on the screen after a few seconds if
the USB drive is recognized.
VOLTAGE CURRENT
VSR LAN RMT ERR DLY ALM ISR M 1 M 2 M 3 RUN
C V C C
V A
If the USB drive is not recognized, check to see that
the function settings for F-20 = 1 (page 103). If not,
reinsert the USB flash drive.
3. Configure T-03 (Test Export) to
1~10 (save memory slot)
4. The script will now be copied to the USB flash
drive.
OK will be displayed when completed.
Error messages: If you try to export a test script from
an empty memory location “Err 002” will be displayed
on the display.
VOLTAGE CURRENT
VSR LAN RMT ERR DLY ALM ISR M 1 M 2 M 3 RUN
C V C C
V A
Remove Test Script
The Remove Test function will delete a test script
from the internal memory.
1. Select T-04 (Test Remove) and
choose which test script to remove
from the internal memory.
