PSU Series User Manual
196
Trigger Input and Output
Configuration Settings
Setting
Default Setting
Trigger Input Pulse
Width
F100
0 = trigger controlled by trigger level.
Trigger Input Action
F102
0 = None
Output State When
Receiving Trigger
F103
0 = OFF
Apply Voltage Setting on
Trigger
F104
0 = 0V
Apply Current Setting on
Trigger
F105
0 = 0A
Recall memory number
F106
1 = M1
Trigger Output Pulse
Width
F120
0ms
Trigger Output Level
F121
0 = LOW
Trigger Source
F122
0 = None
