6-5
Figure 6-8 MSR 30-20 internal structure
(1)
(2)
(3)
(4) (5)
(6) (7)
(8)(9)(10)
(1) Power module (2) VPM
(3) CF card slot (4) VCPM slot
(5) ESM slot 1 (6) MIM card slot
(7) SIC slot (8) Fan module
(9) Memory module slot (10) ESM slot 0
Figure 6-9 Internal structure of the MSR 30-40/30-60 (Before the power module is removed)
(1)
(2)
(3)
(4)
(1) Power module (2) Power bracket
(3) Fan module (4) CF card slot
