1-6
Item S5130S-10P-EI S5130S-12TP-EI S5130S-20P-EI
form combo interfaces with
their corresponding SFP ports,
respectively.)
SFP port 2
4 (The two lowest-numbered
SFP ports form combo
interfaces with their
corresponding
10/100/1000BASE-T
autosensing Ethernet ports,
respectively.)
4
Input voltage
• Rated voltage: 100 VAC to 240 VAC @ 50 or 60 Hz
• Max voltage: 90 VAC to 264 VAC @ 47 to 63 Hz
Minimum power
consumption
7 W 8 W 9 W
Maximum power
consumption
12 W 15 W 19 W
Chassis leakage
current
compliance
UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC 60950-1/GB4943.1
Melting current of
power supply fuse
2 A/250 V 2 A/250 V 2 A/250 V
Cooling system Passive cooling Passive cooling Passive cooling
Operating
temperature
–5°C to +45°C (23°F to 113°F)
Operating
humidity
5% to 95%, noncondensing
Fire resistance
compliance
UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC 60950-1/GB4943.1
Table1-3 Technical specifications for non-PoE switch models (2)
Item
S5130S-28P-EI
S5130S-28P-EI-M
S5130S-52P-EI
S5130S-52P-EI-M
Dimensions (H × W
× D)
43.6 × 440 × 160 mm (1.72 × 17.32 ×
6.30 in)
43.6 × 440 × 230 mm (1.72 × 17.32 × 9.06 in)
Weight ≤ 2.5 kg (5.51 lb) ≤ 3.5 kg (7.72 lb)
Console port 1 × serial console port 1 × serial console port
10/100/1000BASE-
T autosensing
Ethernet port
24 48
SFP port 4 4
Input voltage
• Rated voltage: 100 VAC to 240 VAC @ 50 or 60 Hz
• Max voltage: 90 VAC to 264 VAC @ 47 to 63 Hz
Minimum power
consumption
9 W 18 W
Maximum power
consumption
23 W 41 W
UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC
