H3C S5130S-EI series - S5130 S-28 P-Ei;S5130 S-28 P-Ei-M; S5130 S-28 Tp-Ei

2-23
S5130S-28P-EI/S5130S-28P-EI-M
Figure2-7 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) SFP port LED
(4) System status LED (SYS)
(5) Console port (CONSOLE)
(6) SFP port
Figure2-8 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
S5130S-28TP-EI
Figure2-9 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) SFP port
(3) Console port (CONSOLE)
(4) Micro USB console port
(5) 10/100/1000BASE-T autosensing Ethernet port LED
(6) System status LED (SYS)
(7) SFP port LED
1
5
2
3
6
4
2
1
1
2
3 4
7
5
6
