H3C S5130S-EI series - S5130 S-28 S-Hpwr-Ei-Ac

2-47
S5130S-28S-HPWR-EI-AC
Figure2-77 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) SFP port
(3) Console port (CONSOLE)
(4) Port LED mode switching button
(5) 10/100/1000BASE-T autosensing Ethernet port LED
(6) System status LED (SYS)
(7) Mode LED (MODE)
(8) SFP+ port LED
(9) SFP port LED
(10) Micro USB console port
(11) SFP+ port
Figure2-78 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
1 4
6
3 52
11 9
78
10
1
2
