H3C S5130S-EI series - Setting up an IRF Fabric; Planning IRF Fabric Setup

2-25
S5130S-52TP-EI
Figure2-13 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) Console port (CONSOLE)
(4) Micro USB console port
(5) System status LED (SYS)
(6) SFP port LED
(7) SFP port
Figure2-14 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
S5130S-28S-EI/S5130S-28S-EI-M
Figure2-15 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) SFP+ port LED
(4) System status LED (SYS)
(5) Micro USB console port
(6) Console port (CONSOLE)
(7) SFP+ port
1
2
7
5
6
3
4
1
2
1
2
1
57
2 3
6 4
