2-38
Figure2-51 Rear panel
(1) AC-input power receptacle
(2) Heat sink
(3) Grounding screw
S5130S-28S-PWR-EI
Figure2-52 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) Port LED mode switching button
(3) 10/100/1000BASE-T autosensing Ethernet port LED
(4) SFP+ port LED
(5) System status LED (SYS)
(6) Mode LED (MODE)
(7) Micro USB console port
(8) Console port (CONSOLE)
(9) SFP+ port
Figure2-53 Rear panel (product code LS-5130S-28S-PWR-EI)
(1) Grounding screw
(2) AC-input power receptacle
1
2
3
1
3
5
2
4
78
6
9
1 2
