2-46
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) Console port (CONSOLE)
(4) Port LED mode switching button
(5) System status LED (SYS)
(6) Mode LED (MODE)
(7) Micro USB console port
(8) SFP+ port
(9) SFP+ port LED
Figure2-74 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
S5130S-28P-HPWR-EI-AC
Figure2-75 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) Console port (CONSOLE)
(3) Port LED mode switching button
(4) 10/100/1000BASE-T autosensing Ethernet
port LED
(5) System status LED (SYS)
(6) Mode LED (MODE)
(7) SFP port LED
(8) SFP port
Figure2-76 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
1
2
1 3 52
8
4
7 6
1
2
