H3C S5130S-EI series - S5130 S-52 S-Pwr-Ei

2-41
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) Console port (CONSOLE)
(4) 10/100/1000BASE-T autosensing Ethernet port LED
(5) System status LED (SYS)
(6) Mode LED (MODE)
(7) SFP+ port LED
(8) Micro USB console port
(9) SFP+ port
Figure2-60 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
(3) Heat sink
S5130S-52S-PWR-EI
Figure2-61 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) Console port (CONSOLE)
(4) Port LED mode switching button
(5) System status LED (SYS)
(6) RPS status LED (RPS)
(7) Mode LED (MODE)
(8) Micro USB console port
(9) SFP+ port
(10) SFP+ port LED
Figure2-62 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
(3) DC-input power receptacle
1
2
3
1 3 4
6
2 5
7810 9
1
2 3
