H3C S5130S-EI series - Verifying the Installation

2-22
Figure2-4 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
S5130S-20P-EI
Figure2-5 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) SFP port LED
(4) System status LED (SYS)
(5) Console port (CONSOLE)
(6) SFP port
Figure2-6 Rear panel
(1) AC-input power receptacle
(2) Grounding screw
2
1
1 2
3
4
6
5
1 2
