Figure2-36 Rear panel
(1) AC-input power receptacle
(2) Grounding screw
S5130S-12TP-HPWR-EI
Figure2-37 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) SFP port LED
(4) System status LED (SYS)
(5) Mode LED (MODE)
(6) Port LED mode switching button
(7) Console port (CONSOLE)
(8) SFP port
Figure2-38 Rear panel
(1) AC-input power receptacle
(2) Grounding screw
