H3C S5130S-EI series - S5130 S-28 S-Hpwr-Ei-Q; S5130 S-28 S-Upwr-Ei-Q

2-40
S5130S-28S-HPWR-EI-Q
Figure2-57 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) Port LED mode switching button
(3) 10/100/1000BASE-T autosensing Ethernet port LED
(4) SFP+ port LED
(5) System status LED (SYS)
(6) Mode LED (MODE)
(7) Micro USB console port
(8) Console port (CONSOLE)
(9) SFP+ port
Figure2-58 Rear panel
(1) AC-input power receptacle
(2) Heat sink
(3) Grounding screw
S5130S-28S-UPWR-EI-Q
Figure2-59 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) Console port (CONSOLE)
(3) Port LED mode switching button
1
7
9
3
4
8
6
2
5
1 2
3
9
2
8
3
4
7
5
6
1
