H3C S5130S-EI series - 2.5 G;1000;100 BASE-T Autosensing Ethernet Port; 10;5;2.5;1 GBASE-T Autosensing Ethernet Port

4-51
Item Specification
• 5 Gbps, full duplex
• MDI/MDI-X autosensing
Max transmission distance
• 5G mode: 100 m (328.08 ft) over Category-5e or above
twisted pair
• 2.5G mode: 200 m (656.17 ft) over Category-5e or above
twisted pair
• 1G mode: 200 m (656.17 ft) over Category-5e or above
twisted pair
Transmission medium Category-5e (or above) twisted pair cable
Compatible standards
• IEEE 802.3ab
• IEEE 802.3an
2.5G/1000/100BASE-T autosensing Ethernet port
The S5130S-10MS-UPWR-EI switch provides 2.5G/1000/100BASE-T autosensing Ethernet ports.
Table4-5 2.5G/1000/100BASE-T autosensing Ethernet port specifications
Item Specification
Connector type RJ-45
Transmission rate, duplex mode, and
auto MDI/MDI-X
• 2.5 Gbps, full duplex
• 1 Gbps, full duplex
• 100 Mbps, full duplex
• MDI/MDI-X autosensing
Max transmission distance
• 2.5G mode: 200 m (656.17 ft) over Category-5e or above
twisted pair
• 1G mode: 200 m (656.17 ft) over Category-5e or above
twisted pair
• 100M mode: 200 m (656.17 ft) over Category-5e or above
twisted pair
Transmission medium Category-5e (or above) twisted pair cable
Compatible standards
• IEEE 802.3ab
• IEEE 802.3an
10/5/2.5/1GBASE-T autosensing Ethernet port
The S5130S-28ST-EI, S5130S-52ST-EI, S5130S-28ST-PWR-EI, and S5130S-52ST-PWR-EI
switches provide 10/5/2.5/1GBASE-T autosensing Ethernet ports.
Table4-6 10/5/2.5/1GBASE-T autosensing Ethernet port specifications
Item Specification
Connector type RJ-45
Transmission rate, duplex mode, and
auto MDI/MDI-X
• 10 Gbps, full duplex
• 5 Gbps, full duplex
• 2.5 Gbps, full duplex
• 1 Gbps, full duplex
• MDI/MDI-X autosensing
