H3C S5130S-EI series Hardware Information

1-11
Table1-7 Technical specifications for non-PoE switch models (6)
Item S5130S-28S-EI-DP
S5130S-28ST-
EI
S5130S-52ST-EI
S5130S-28PS-
EI
Dimensions (H
× W × D)
43.6 × 440 × 260 mm
(1.72 × 17.32 × 10.24
in)
43.6 × 440 ×160
mm (1.72 × 17.32
× 6.30 in)
43.6 × 440 × 260 mm
(1.72 × 17.32 × 10.24
in)
43.6 × 440 × 360
mm (1.72 × 17.32
× 14.17 in)
Weight ≤ 3.5 kg (7.72 lb) ≤ 2.5 kg (5.51 lb) ≤ 4 kg (8.82 lb) ≤ 4.5 kg (9.92 lb)
Console port
• 1 × serial console
port
• 1 × micro USB
console port
When both ports are
connected, only the
micro USB console
port is available.
1 × serial console port
10/100/1000B
ASE-T
autosensing
Ethernet port
24 24 48
24 (The eight
highest-numbere
d
10/100/1000BAS
E-T autosensing
Ethernet ports
form combo
interfaces with
their
corresponding
SFP ports,
respectively.)
10/5/2.5/1GBA
SE-T
autosensing
Ethernet port
N/A 2 2 N/A
SFP port N/A N/A N/A
8 (The eight SFP
ports form combo
interfaces with
their
corresponding
10/100/1000BAS
E-T autosensing
Ethernet ports,
respectively.)
SFP+ port 4 2 2 4
Input voltage
AC power source:
• Rated voltage: 100 VAC to 240 VAC @ 50 or 60 Hz
• Max voltage: 90 VAC to 264 VAC @ 47 to 63 Hz
DC power source (supported only by the S5130S-28PS-EI switch):
• Rated voltage:–24 VDC to –48 VDC
• Max voltage: –24 VDC to –48 VDC
Minimum
power
consumption
Single AC input: 11 W
Dual AC inputs: 15 W
AC: 14 W AC: 22 W
AC: 12 W
DC: 11 W
Maximum
power
consumption
Single AC input: 25 W
Dual AC inputs: 26 W
AC: 36 W AC: 53 W
AC: 31 W
DC: 26 W

H3C S5130S-EI series Specifications

General

Series	S5130S-EI
Category	Switch
MAC Address Table Size	16K
VLAN	4K VLANs
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	5% to 95% (non-condensing)
Ports	10/100/1000BASE-T ports
Layer Support	Layer 3
Stacking	Supported
Power Supply	AC/DC
PoE	Supported on some models
Dimensions (W x D x H)	440 x 43.6 mm
