696LE005550A
Function of the Energy trip unit
3.4 Managing alarms and logs
Measurement monitored
Possible
activation
conditions
Activation/
deactivation
threshold ranges
Version
3P
Version
4P
Power
Active power consumed per phase
>
<
1 kW to 1000 kW
(increments of 0.1 kW)
– X
Total active power consumed
>
<
1 kW to 3000 kW
(increments of 0.1 kW)
X X
Active power generated per phase
>
<
1 kW to 1000 kW
(increments of 0.1 kW)
– X
Total active power P
>
<
1 kW to 3000 kW
(increments of 0.1 kW)
X X
Reactive power consumed per phase
Q1, Q2, Q3
>
<
1 kvar to 1000 kvar
(increments of 0.1
kvar)
– X
Total reactive power consumed Q
>
<
1 kvar to 3000 kvar
(increments of 0.1 kvar)
X X
Reactive power returned per phase
Q1, Q2, Q3
>
<
1 kvar to 1000 kvar
(increments of 0.1
kvar)
– X
Total reactive power returned Q
>
<
1 kvar to 3000 kvar
(increments of 0.1
kvar)
X X
Apparent power per phase S1, S2,
S3
>
<
1 kVA to 1000 kVA
(increments of 0.1 kVA)
– X
Total apparent power S
>
<
1 kVA to 3000 kVA
(increments of 0.1 kVA)
X X
Capacitive power factor per phase <
0 to 0.99
(increments of 0.01)
– X
Total capacitive power factor <
0 to 0.99
(increments of 0.01)
X X
Inductive power factor per phase <
0 to 0.99
(increments of 0.01)
– X
Total inductive power factor <
0 to 0.99
(increments of 0.01)
X X
Cos phi
Capacitive cos phi per phase <
0 to 0.99
(increments of 0.01)
– X
Total capacitive cos phi <
0 to 0.99
(increments of 0.01)
X X
Inductive cos phi per phase <
0 to 0.99
(increments of 0.01)
– X
Total inductive cos phi <
0 to 0.99
(increments of 0.01)
X X
Distortion level
Total harmonic distortion of current
per phase THDI1, THDI2, THDI3
>
0% to 1000%
(increments of 0.1%)
X X
Total harmonic distortion of
phase-neutral voltages THDV1N,
THDV2N, THDV3N
>
0% to 1000%
(increments of 0.1%)
– X
Total harmonic distortion of phase-
phase voltages THDU12, THDU23,
THDU31
>
0% to 1000%
(increments of 0.1%)
X X
