hager h3+ User Manual

1056LE005550A
Starting, commissioning, operation
4.7 Commissioning via the HTP610H configuration tool
4.7.1
Preparing the HTP610H tool
ATTENTION
The following instructions and explanations are also described more
comprehensively in the HTP610H configuration tool user manual.
Consult the user manual for the HTP610H configuration tool beforehand
to read the advice and instructions for using the tool.
The HTP610H configuration tool operates autonomously thanks to an integrated
rechargeable battery.
Ensure that the HTP610H tool is suciently charged before use.
Connecting the charger to the mains supply
Configuration unit connected to mains supply
Connecting to the h3+ circuit breaker
The MIP adapter and the connection cable supplied with the tool enabling the
configuration tool to be connected to the h3+ circuit breaker.
Configuration unit connection
