96LE005550A
About this manual
1.3 Abbreviations
ACP Auxiliary Communication Port: Connector for the AX/AL
Energy auxiliary
AL ALarm: Fault-signal auxiliary contact
AX AuXiliary: Open/closed auxiliary contact
CIP Communication Interface Port: Connector for the panel
display and communication module
MIP Maintenance Interface Port: connector for HTP610H
configuration tool
OAC Optional Alarm Contact: Connector for the optional alarm
output contact
PTA Pre-Trip Alarm: Overload pre-alarm and connector for the
overload pre-alarm output contact
LCD Liquid Crystal Display
SSID Service Set Identifier (name of wireless Wi-Fi network)
SELV Safety Extra Low Voltage
URL Uniform Resource Locator (Internet website address)
ZSI Zone Selective Interlocking (selectivity per zone).
