200 kHz LCR-Bridge HM8118
All data valid at 23 °C after 30 minutes warm-up.
Conditions
Test signal voltage: 1 V
Open and short corrections performed
Measurement time: SLOW
Display
Measurement modes:
Auto, L-Q, L-R, C-D, C-R, R-Q, Z-Θ, Y-Θ,
R-X, G-B, N-Θ, M
Equivalent circuits: Auto, Series or Parallel
Parameters displayed: Value, Deviation or % Deviation
Averaging: 2…99 measurements
Accuracy
Primary Parameters: Basic accuracy
(Test voltage: 1.0 V,
measurement SLOW/MEDIUM,
autoranging mode, constant voltage OFF,
bias off). For FAST mode double the basic
accuracy values
Secondary Parameters:
Basic accuracy D, Q: ±0.0001
@ f = 1 kHz
Phase angle: ±0.005°
@ f = 1 kHz
Ranges
|Z|, R, X: 0.01 mΩ…100 MΩ
|Y|, G, B: 10 nS…1,000 S
C: 0.01 pF…100 mF
L: 10 nH…100 kH
D: 0.0001…9.9999
Q: 0.1…9,999.9
Θ:
-180…+180°
∆: -999.99…999.99 %
M: 1 µH…100 H
N: 0.95…500
Measurement conditions and functions
Test frequency: 20 Hz…200 kHz (69 steps)
Frequency accuracy: ±100 ppm
AC test signal level: 50 mV
rms
…1.5 V
rms
(with active constant voltage setting)
Resolution 10 mV
rms
Drive level accuracy: ±(5 % + 5 mV)
Internal Bias Voltage: 0…+5.00 V
dc
Resolution 10 mV
External Bias Voltage: 0…+40 V
dc
(fused 0.5 A)
Internal Bias Current: 0…+200 mA
Resolution 1 mA
Range Selection: Auto and Hold
Trigger: Continuous, manual or external via
interface, Binning Interface or Trigger
Input
Trigger delay time: 0…999 ms in 1 ms steps
Measurement time (f ≥1 kHz):
FAST 70 ms
MEDIUM 125 ms
SLOW 0.7 s
Other Instrument Functions
Test signal level monitor: Voltage, current
Error Correction: Open, Short, Load
Save/Recall: 9 instrument settings
Front-end Protection:
V
max
<Z
X
2/C @ V
max
<200 V, C in Farads
(1 Joule of stored energy)
Low Potential and
Low Current Guarding:
Ground, Driven Guard or Auto (fused)
Constant Voltage Mode (25 Ω source):
Temperature effects
R, L or C ±5 ppm/°C
Interface: Dual-Interface USB/RS-232 (HO820),
IEEE-488 (GPIB) (optional)
Safety Class: Safety Class I (EN61010-1)
Power supply: 110…230 V ±10 %, 50…60 Hz, CAT II
Power consumption: approx. 20 W
Operating temperature: +5…+40 °C
Storage temperature: -20…+70 °C
Rel. humidity: 5…80 % (non condensing)
Dimensions (W x H x D): 285 x 75 x 365 mm
Weight: approx. 4 kg
Accessories supplied: Line cord, Operating manual, HZ184 4 Terminal Kelvin
Test Cable and HZ188 4 Terminal SMD Component Test Fixture, CD
Recommended accessories:
HO118 Binning Interface
HO880 Interface IEEE-488 (GPIB), galvanically isolated
HZ13 Interface cable (USB) 1.8 m
HZ14 Interface cable (serial) 1:1
HZ33 Test cable 50 Ω, BNC/BNC, 0.5 m
HZ34 Test cable 50 Ω, BNC/BNC, 1.0 m
HZ42 19" Rackmount kit 2RU
HZ72 GPIB-Cable 2 m
HZ181 4 Terminal Test Fixture including Shorting Plate
HZ186 4 Terminal Transformer Test Cable
HM8118E/160812 · C&E · Subject to change without notice · © HAMEG Instruments GmbH
®
· DQS-certified in accordance with DIN EN ISO 9001:2008, Reg.-No.: 071040 QM08
HAMEG Instruments GmbH · Industriestr. 6 · D-63533 Mainhausen · Tel +49 (0) 6182 8000 · Fax +49 (0) 6182 800100 · www.hameg.com · info@hameg.com
200 kHz LCR-Bridge HM8118
All data valid at 23 °C after 30 minutes warm-up.
Conditions
Test signal voltage:
1 V
Open and short corrections performed
Measurement time:
SLOW
Display
Measurement modes:
Auto, L-Q, L-R, C-D, C-R, R-Q, Z-Θ, Y-Θ,
R-X, G-B, N-Θ, M
Equivalent circuits:
Auto, Series or Parallel
Parameters displayed:
Value, Deviation or % Deviation
Averaging:
2…99 measurements
Accuracy
Primary Parameters:
Basic accuracy
(Test voltage: 1.0 V,
measurement SLOW/MEDIUM,
autoranging mode, constant voltage OFF,
bias off). For FAST mode double the basic
accuracy values
0.2% + |Z|/1.5GΩ
Impedance:
100MΩ
4MΩ
1MΩ
25kΩ
100Ω
2.5Ω
0.01mΩ
20Hz 1kHz 10 kHz100kHz
0.1% + 1mΩ/|Z|
0.3% + 1mΩ/|Z|
0.05% +
|Z|/2GΩ
0.1% +
|Z|/1,5GΩ
0.5% +
|Z|/100MΩ
0.2% +
|Z|/100MΩ
0.2% +
2mΩ/|Z|
0.5% +
5mΩ/|Z|
+
|Z|/10MΩ
0.5% +
2mΩ/|Z|
Secondary Parameters:
Basic accuracy D, Q: ±0.0001
@ f = 1 kHz
Phase angle: ±0.005°
@ f = 1 kHz
Ranges
|Z|, R, X:
0.01 mΩ…100 MΩ
|Y|, G, B:
10 nS…1,000 S
C:
0.01 pF…100 mF
L:
10 nH…100 kH
D:
0.0001…9.9999
Q:
0.1…9,999.9
Θ:
-180…+180°
∆:
-999.99…999.99 %
M:
1 µH…100 H
N:
0.95…500
Measurement conditions and functions
Test frequency:
20 Hz…200 kHz (69 steps)
Frequency accuracy:
±100 ppm
AC test signal level:
50 mV
rms
…1.5 V
rms
Resolution
10 mV
rms
Drive level accuracy:
±(5 % + 5 mV)
Internal Bias Voltage:
0…+5.00 V
dc
Resolution
10 mV
External Bias Voltage:
0…+40 V
dc
(fused 0.5 A)
Internal Bias Current:
0…+200 mA
Resolution
1 mA
Range Selection:
Auto and Hold
Trigger:
Continuous, manual or external via
interface, Binning Interface or Trigger
Input
Trigger delay time:
0…999 ms in 1 ms steps
Measurement time (f ≥1 kHz):
FAST
70 ms
MEDIUM
125 ms
SLOW
0.7 s
Other Instrument Functions
Test signal level monitor:
Voltage, current
Error Correction:
Open, Short, Load
Save/Recall:
9 instrument settings
Front-end Protection:
V
max
<
Z
X
2/C
@ V
max
<200 V, C in Farads
(1 Joule of stored energy)
Low Potential and
Low Current Guarding:
Ground, Driven Guard or Auto (fused)
Constant Voltage Mode (25 Ω source):
Temperature effects
R, L or C
±5 ppm/°C
Interface:
Dual-Interface USB/RS-232 (HO820),
IEEE-488 (GPIB) (optional)
Safety Class:
Safety Class I (EN61010-1)
Power supply:
110…230 V ±10 %, 50…60 Hz, CAT II
Power consumption:
approx. 20 W
Operating temperature:
+5…+40 °C
Storage temperature:
-20…+70 °C
Rel. humidity:
5…80 % (non condensing)
Dimensions (W x H x D):
285 x 75 x 365 mm
Weight:
approx. 4 kg
Accessories supplied: Line cord, Operating manual, HZ184 4 Terminal Kelvin
Test Cable and HZ188 4 Terminal SMD Component Test Fixture, CD
Recommended accessories:
HO118 Binning Interface
HO880 Interface IEEE-488 (GPIB), galvanically isolated
HZ13 Interface cable (USB) 1.8 m
HZ14 Interface cable (serial) 1:1
HZ33 Test cable 50 Ω, BNC/BNC, 0.5 m
HZ34 Test cable 50 Ω, BNC/BNC, 1.0 m
HZ42 19" Rackmount kit 2RU
HZ72 GPIB-Cable 2 m
HZ181 4 Terminal Test Fixture including Shorting Plate
HZ186 4 Terminal Transformer Test Cable
