19
Filling Non-Recirculating Tank
(Option)
1. Remove the cap from the cooling tank.
2. Fill the cooling tank with distilled or
deionized water until the water begins
to flow from the cooling tank into the
collection bottle (or into the drain if the
overflow tube is installed).
3. Replace the cap.
Emptying Collection Bottle
1. Empty the collection bottle when the
water in the bottle reaches the FULL
mark.
2. Slide the bottle away from the cooling
tank to remove.
3. Pour the contents down the drain.
OPERATION
Note
The cooling tank must be
connected to the sterilizer before
filling the tank with water.
Note
Do not operate sterilizer unless
the cooling tank is filled with
distilled or deionized water and
attached to the sterilizer.
Hot Surface
Burn Hazard: Do not empty the
collection bottle when the
sterilizer is in operation.
Note
It is important to periodically
check the water level in the
collection bottle. Failure to empty
the bottle when full will result in
water overflowing onto
surrounding surfaces.
Figure 9
Emptying Collection Bottle
Optional
Overflow
Drain
Waste Water
Cooling
Tank
Collection
Bottle
From
Sterilizer
Figure 8
Non-Recirculating Water Accessory
Fill With Distilled or
Low Quality Deionized
Water Until It Overflows
Into the Collection Bottle
(Approx. 3 Gal.)
Collection
Bottle
Remove Cap
Optional
Overflow
Drain
Full Mark
To Next Page
