37
OPERATOR MAINTENANCE
When Required
Emptying Non-Recirculating
Collection Bottle
Empty the collection bottle when the water in
the bottle reaches the FULL mark.
Slide the bottle away from the cooling tank to
remove.
Pour the contents down the drain.
Cleaning Printer Recess (MC10)
The MC10 printer may be removed to allow
cleaning of the recessed area. See the “Printer”
section for removal procedure. Use a mild
disinfectant to clean the recess.
Replacing Door Gasket
1. Open the sterilizer door and remove
the hex nut in the center of the gasket
retainer and remove the gasket
retainer and gasket.
2. Clean surface of the door plate, new
gasket and gasket retainer of any dirt,
adhesives or deposits.
3. Apply a generous amount of silicone
multipurpose sealant (available in
most hardware stores) in a 2” diameter
area around the center stud of the
door plate.
Figure 28
Door Gasket Replacement
Hot Surface
Burn Hazard: Do not empty the
collection bottle when the
sterilizer is in operation.
Note
It is important to periodically
check the water in the collection
bottle. Failure to empty the bottle
when full will result in water
overflowing onto surrounding
surfaces.
Note
The gasket is adhered to the door
plate and must be pulled loose.
Note
Allow about an hour for the silicone
sealant to set, then run a no-load
cycle to seat gasket.
Silicon (RTV)
Sealant
Gasket
Gasket
Retainer
Hex Nut
Hole At Bottom
Gasket Retainer
(Chamber Side)
Gasket
Door Side
Section Of
Door Gasket and
Gasket Retainer
To Next Page
