53
230 VAC to 115 VAC
Parts Required
• two 15 AMP time delay fuses (Part No.
266058)
• jumper for Power I/O Board
• jumper for Transformer PC Board
• suitable 115 VAC plug or plug adapter
1. On the Power I/O PC Board: Remove
jumper from J7 to J8. Install jumpers
from J5 to J7 and from J3 to J8.
2. Move black heater wire from J11 to
J14. Move white heater wire from J12
to J11. Leave the other black wire
connected.
3. On the Transformer PC Board (MC10
with printer only): Remove jumper from
JMP3 position and install jumpers in
JMP1 and JMP2 positions.
4. Install the 15 AMP fuses in
fuseholders.
5. Reinstall the left side panel, rear
access panel and pressure relief valve
deflection cover.
6. Use either a plug adapter or remove
the power cord plug and install a
suitable 115 VAC plug.
7. Tag the sterilizer as configured for 115
VAC.
APPENDIX
