50
115 VAC to 230 VAC
Parts Required
• Two 8 Amp time delay fuses (Part No.
264306)
• Suitable 230 VAC plug or plug adapter
1. On the Power I/O PC Board: Remove
jumpers from J5 to J7 and J3 to J8.
Install jumper from J7 to J8. (Save other
jumper for future reconversion to 115
VAC.)
2. Move white heater wire from J11 to J12.
Move black heater wire from J14 to J11.
Leave other black wire connected.
3. On the Transformer PC Board (MC10
with Printer Only): Remove jumpers from
JMP1 and JMP2 positions and install
jumper in JMP3 position. (Save other
jumper for future reconversion to 115
VAC.)
4. Install the 8 Amp fuses in fuseholders.
5. Reinstall the left side panel, rear access
panel, and pressure relief valve
deflection cover.
6. Use either a plug adapter or remove the
power cord plug and install a suitable
230 VAC plug.
7. Tag the sterilizer as configured for 230
VAC.
APPENDIX
