48
Technical Data
* Dual-voltage government models meet the
requirements of IEC 11.36 L (approximately 3
gallons)- Class I, Type B equipment.
Cabinet Size 13-1/2” W x 16” H x 22” L 16” W x 18” H x 23” L
(33 mm W x 406mm H x 559mm L) (406mm W x 457mm H x 584mm L)
Chamber Size 8” diameter x 14-1/2” usable depth 10” diameter x 15-1/2” usable depth
(203mm diameter x 368mm) (254mm diameter x 393mm)
Tray Sizes Two 14” x 6-1/4” x 7/8” One 15-1/4” x 9” x 1-1/4”
(356mm x 135mm x 22mm) (387mm x 228mm x 32mm)
Shipping Weight 72 lbs (33 kg) 92 lbs (42 kg)
Heater Wattage 1350 Watts 1425 Watts
Electrical Rating 115 VAC, 50/60 Hz, 12 Amps or 115 Vac, 50-60 Hz, 12 Amps or
230 VAC, 50/60 Hz, 6 Amps 230 VAC, 50/60 Hz, 6 Amps
(See Note) (See Note)
Reservoir Capacity 3000 mL (approx. 3 quarts) 4000 mL (approx. 4 quarts)
Maximum Rated 45 psi (310kPa) 45 psi (310 kPa)
Operating Pressure
Environmental Conditions
Operation 10° to 40°C (50° to 104°F) 10° to 40°C (50° to 104°F)
30% to 70% relative humidity, 30% to 70% relative humidity,
non-condensing non-condensing
Altitude Limit 2,000 meters 2,000 meters
Storage and Transport -20° to 60°C (-4° to 140°F) -20° to 60°C (-4° to 140°F)
10% to 100% relative humidity 10% to 100% relative humidity
Printer (Optional)
Electrical Rating 9 VAC;1 Watt (idle), 9 VAC; 1 Watt (idle),
10 Watts (running) 10 Watts (running)
Non-Recirculating Water Accessory (Optional)
Size 6-3/4” W x 13-1/2” H 15-1/4” L 6-3/4” W x 13-1/2” H 15-1/4” L
(171mm W x 343mm H x 387mm L) (171mm W x 343mm H x 387mm L)
Capacity 11.36 L (approx. 3 gallons) 11.36 L (approx. 3 gallons)
Reservoir Water Distilled or Low quality Deionized Distilled or Low Quality Deionized
water (minimum 0.5 megohm/cm, water (minimum 0.5 megohm/cm,
maximum 1.5 megohm/cm). maximum 1.5 megohm/cm).
MC8MC10
