During measurement you can press
+
−
− to view in the display:
1. Measured values
• MVx measured value channel x
• MVy measured value channel y
2. Process status, “ProcStat”
• Alarm the last process was finished via the alarm window
• OK the last process was OK
• Not OK the last process was not OK
• Started a process has been started and not yet finished
3. Status of the digital inputs and outputs
The MP85 has 5 inputs and 8 outputs.
The MP85DP has 1 input and 4 outputs.
• Input
set, not set
• Output
set, not set
4. Profibus status
BD_SEAR (baud rate search)
WT_PARM (waiting for parameterization)
WT_CONF (waiting for configuration)
DATA_EX (cyclical data traffic)
ERROR (bus error)
