46
PME-MP85
A0897−3.4 enHBM
Resolution, single turn Bits 12, 13
Resolution, multi turn Bits 24, 25
Scale range, max. Digits 20 for 1 pulse
Scale range, min. Digits 1 for 10,000 pulses
Measurement frequency range,
adjustable (-1 dB)
Hz 0.05 − 1000
Sampling rate, max. 1/s 1200
Baud rates kBaud 100, 200, 500, 1000
Coding Gray Code
General specifications
Limit switches
Number 4 per channel
Reference level Gross
Hysteresis % 1 ... 100
Adjustment accuracy Digit 1
Response time, typically (fc=1000 Hz) ms t2
Control outputs
Number 4 (MP85DP) / 8 (MP85)
Nominal voltage, external power supply V
DC
24
Permitted supply voltage range V 10 − 30
Maximum output current per output A 0.5
Short-circuit current, typically
(U
ext
. = 24 V, R
L
t 0.1 Ohm)
A 0.8
Short-circuit period Unlimited
Isolation voltage, typically V
DC
500
Control inputs
Number 1 (MP85DP) / 5 (MP85)
Input voltage range LOW V 0 − 5
Input voltage range HIGH V 10 − 30
Input current, typically (HIGH level = 24V) mA 12
Isolation voltage, typically V
DC
500
CAN interface
Sampling rate, max. 1/s 1200
Protocol CAN 2.0B, CANopen compatible
Hardware bus link to ISO 11898
Baud rates
Maximum cable lengths
Kbit/s
m
1000 500 250 125 100 50 20 10
25 100 250 500 600 1000 10001000
Terminating resistance Connectable by switch
Connection Terminals
Parameter memory (Flash) 31 plus factory settings
