47
PME-MP85
A0897−3.4 en HBM
Multimedia card (memory card on Flash base)
Usable types M-
bytes
8, 16, 32, 64
Data transmission rate, typically K-byte
/s
8
File system DOS
Display
Type Two line, 8 character alphanumeric, LCD
Keyboard Touch-sensitive keypad with three keys
Temperature range
Nominal temperature range
o
C 0 − 50
Operating temperature range
o
C −20 ... +50
Storage temperature range
o
C −20 ... +70
Degree of protection IP20
Dimensions mm 55 x 146 x 156
Weight, approx. g 800
Profibus DP interface (MP85DP only)
Protocol Profibus DP slave, as per DIN 19245−3
Baud rate, max. MBaud 12
Node address 3 − 123, can be set via keyboard
Profibus ID number Hex 699
Configuration data byte 5
Parameter data, max. byte 6 (+7DP standard)
Parameter assignment (asynchronous) to DPV1 standard
Input data, max. byte 142
Output data, max. byte 40
Inputs update rate ms 1 (for 4 measured values)
Outputs update rate ms t10, on zeroing, limit values
Diagnosis data byte 48
Profibus connection 9-pin sub-D (DIN19245-3),
potential-separated from power supply
and signal ground
