Specifications for analysis unit
Max. number of data triples
(channel x); (channel y); (time)
4000 (auto. data reduction)
Sampling rate, max. Hz 2400
Analysis
Max. number of analysis windows 9
Type of window Oblique or straight
Analysis methods per window Plot analysis
Mean value of x or y analysis in window
x coordinates for tolerance windows absolute or relative to the start position, or
relative to the end position
Y coordinates for tolerance windows absolute or
relative to F
min
of tolerance window 2
or
relative to F
max
of tolerance window 2
Stop conditions External stop signal
Target value y + decay time
Target value x + decay time
Standstill recognition
Number of independent parameter sets 31
Switching parameter sets, max. ms 500
Duration of offline evaluation straight
window
ms 15 + 0.15/data pair in window
Duration of offline evaluation oblique
window
ms 15 + 0.3/data pair in window
Statistics (for each parameter set, separately)
Maximum number of fitting processes 4 x 10
9
Number of histogram classes for 2
values (x
max
, x
min
, y
max
, y
min
)
9 per tolerance window
