Page #18 background imageLoading...
Page #18 background image
Mechanical installation
18 A0785-150 HBM: public T10FS
5 Mechanical installation
WARNING
Handle the torque flange carefully! The transducer could
suffer permanent damage from mechanical shock
(dropping), chemical effects (e.g. acids, solvents) or
thermal effects (hot air, steam).
With alternating loads, you should cement the rotor
connection screws into the mating thread with a screw
locking device (medium strength) to exclude prestressing
loss due to screw slackening.
An appropriate shaft flange enables the T10FS torque
flanges to be mounted directly. It is also possible to
mount a joint shaft or relevant compensating element
directly on the rotor (using an intermediate flange when
required). Under no circumstances must the permissible
limits specified for bending moments, lateral and
longitudinal forces be exceeded. Due to the T10FS
torque flanges' high torsional stiffness, dynamic changes
on the shaft train are minimized.
Important
The effect on critical bending speeds and natural
torsional vibrations must be checked to avoid overloading
the measurement flanges due to the resonance stepup.
