Calibration

T10FS A0785-150 HBM: public 57

7.2 Calibration Option 2, code SF1/SU2

Applying a separated extra‐low voltage of 5 V to pin 6 (+)

and 7 ( ) on connector 1 or 3 triggers the calibration

signal.

The nominal (rated) voltage for triggering the calibration

signal is 5 V (triggered when U>2.7 V). The trigger

voltage is electrically isolated from the supply voltage and

the measurement voltage. The maximum permissible

voltage is 30 V. When voltages are less than 0.7 V, the

measurement flange is in measuring mode. Current

consumption at nominal (rated) voltage is approx. 2mA

and at maximum voltage is approx. 22 mA.

Notice

In the case of HBM system solutions, the measuring

amplifier triggers the calibration signal.
