Mechanical installation
36 A0785-150 HBM: public T10FS
5.8.2 Mounting the torque flange with a speed
measuring system
1. Mount the torque flange in the shaft train so that the
bearing surface of the stator base lies on the prepared
mounting surface free from play and stress.
2. Fasten the rotor with 8 screws in the shaft train (for
the property class, see Tab. 5.1, Page 26). Initially,
the screws should only be hand‐tight.
3. Compensate for any possible misalignment of the
stator by putting adjusting washers underneath or by
adjusting the base.
4. Fasten the base retaining screws; only tighten them
gently at first, so that the mounting elements do not
get jammed.
5. Remove the mounting elements (if a mounting
element should get jammed, try to move it to the left
or right).
Notice
It is essential to keep the mounting elements and
fastening screws in case any modifications are needed!
6. Tighten the stator retaining screws. The stator must
rest at the markings or stops. The rotor must turn
freely.
7. Check whether the axial and radial tolerances have
been maintained.
8. With a torque wrench, definitively tighten the fastening
screws of the rotor in a diagonally opposite sequence
(for tightening torques, see Tab. 5.1, Page 26).
