Specifications
T10FS A0785-150 HBM: public 91
13 Specifications
Type T10FS
Accuracy class 0.05
Torque measuring system
Nominal (rated) torque M
nom
Nm 100 200 500 1 k 2 k 3 k 5 k 10 k
Nominal (rated) sensitivity
(spread between
torque = zero and nominal
(rated) torque)
Frequency output kHz 5
Voltage output V 10
Sensitivity tolerance
(deviation of the actual output
quantity at M
nom
from the
nominal (rated) sensitivity)
Frequency output % ±0.1
Voltage output % ±0.2
Output signal at
torque = zero
Frequency output kHz 10
Voltage output V 0
Nominal output signal
Frequency output
at positive nominal (rated)
torque
kHz 15 (5 V symmetrical
1
/12 V asymmetrical
2
)
at negative nominal (rated)
torque
kHz 5 (5 V symmetrical
1
/12 V asymmetrical
2
)
Voltage output
at positive nominal (rated)
torque
V +10
