HBM T10FS User Manual

Specifications
92 A0785-150 HBM: public T10FS
Nominal (rated) torque M
nom
10 k5 k3 k2 k1 k500200100N⋅m
at negative nominal (rated)
torque
V -10
Load resistance
Frequency output kΩ ≥2
Voltage output kΩ ≥5
Long‐term drift over 48 h
Voltage output mV ≤±3
Measurement frequency
range
Voltage output Hz 0 ... 1000 (-3 dB)
Group delay
Frequency output ms 0.15
Voltage output ms 0.9
Residual ripple
Voltage output mV 40 (peak‐to‐peak)
Temperature effect per 10 K
in the nominal (rated)
temperature range
on the output signal, related
to the actual value of the
signal spread
Frequency output % <±0.05
Voltage output % <±0.15
on the zero signal, related to
the nominal (rated)
sensitivity
Frequency output % <±0.05 (optional <±0.03)
Voltage output % <±0.15 (optional <±0.13)
